EFS suspension kit with 40mm lift for the SsangYong (KGM) Musso Q200 12/2021 onwards model.

Suspension lift kits are designed to maintain factory rake. Feel free to contact us to discuss options for your vehicle.

Fitment notes

Rear Suspension

  • Tail shaft spacer only required if vibration is present.
  • Some vehicles may require a rear panhard rod.
Product Details

Warranty

Each part in this kit is covered by its own manufacturer warranty. View the full warranty details.

EFS Shocks

EFS provide a range of affordable, quality shock absorbers to suit all types of 4WD, whether you are an on-road only user, off the beaten track tourer or serious offroader. EFS Shock Absorbers are vehicle and height specific. "Not a one shock suits all approach".

General Specifications

  • Long Travel Design - Maximises wheel articulation
  • Twin Tube Construction - Increased control of the spring during rebound and compression cycles
  • Quality Hardened Chromed Piston Rods Longer service life, and greater lateral strength
  • 5mm Outer & Inner Wall Thickness Greater durability and strength
  • Dynamic Motion Control Valve - Adjusts to different road & off road conditions
  • Polyurethane and rubber bushes – HI quality elastomer and rubber mounting bushes to suit specific applications

EFS Coil Springs

EFS Coil Springs are manufactured under a strict quality control system with the use of quality Spring steel. This ensures you are purchasing a high-quality product that is backed by a three year/100,000km warranty.

EFS Coil Springs are produced in a variety of raised heights, from standard to 125mm and also a variety of spring rates to suit different applications - Towing, load bearing accessories, increased ride height and off-road competition.

Specifications

  • Shot Peened - To stress relieve the outer surface of the Coil, so the Coil can operate under higher fatigue & repeated load conditions to ensure longevity.
  • Scragged for Quality Control -This is a process where the Coil is compressed beyond its yield point; this compression will set-up residual stresses and increase the elastic limit of the spring.
  • Powder Coated - To resist corrosion & to protect the spring steel from minor damage.

EFS Panhard Rods

The EFS adjustable Panhard Rod corrects the lateral location of the diff and centralises the diff location. When a 4WD is lifted beyond a certain height the diff is pulled across by the standard panhard rod.

EFS Panhard Rods are made from high-strength steel with high-performance polyurethane bushes.

Lift Kit - Ssangyong (KGM) Musso Q200 12/2021+ - 40mm lift

Lift Kit - Ssangyong (KGM) Musso Q200 12/2021+ - 40mm lift

EFS4x4

Options
Buy now, pay later with Afterpay

Front Suspension

Shock Options

EFS Elite - 35mm Bore

Part number: 38-5660

$321.20 EACH
Kit requires: 2
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$321.20 EACH
Kit requires: 2
$642.40
2

Coil Springs

EFS Coils - up to 50kg

Part number: SSG-103HE

$447.15 PAIR
Kit requires: 1
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$447.15 PAIR
Kit requires: 1
$447.15
1

Rear Suspension

Shock Options

EFS Elite - 35mm Bore

Part number: 36-5602

$231.84 EACH
Kit requires: 2
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$231.84 EACH
Kit requires: 2
$463.68
2

Coil Springs

EFS Coils - Constant load 150kg

Part number: SSG-205E

$442.70 PAIR
Kit requires: 1
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$442.70 PAIR
Kit requires: 1
$442.70
1
EFS Coils - Constant load 250kg

Part number: SSG-205HE

$442.70 PAIR
Kit requires: 1
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$442.70 PAIR
Kit requires: 1
$442.70
1

Rear Suspension - Optional

Tail Shaft Spacer

EFS Tail Shaft Spacer

Part number: 10-1118

$124.37 EACH
Kit requires: 1
$124.37 EACH
Kit requires: 1
$124.37
1

Panhard Rod

EFS Adjustable Panhard Rod

Part number: 10-1150

$389.40 EACH
Kit requires: 1
We have stock arriving regularly. Feel free to call us (09 427 8294) to check lead times before ordering.
$389.40 EACH
Kit requires: 1
$389.40
1

Order Summary

Product Description Part Number Per Unit Price Quantity Total
Subtotal $0.00
